ALLIANCE edgeROU

ALLIANCE N2ROU

ALLIANCE N2ROU

ALLIANCE MROU

ALLIANCE HROU

ALLIANCE MID-BAND HROU

ALLIANCE MID-BAND HROU

ALLIANCE MPROU

ALLIANCE MPROU

ALLIANCE iBIU

ALLIANCE iBIU

ALLIANCE DMS

ALLIANCE DMS
DAS Management System

ALLIANCE edgeROU

Documentation Resources
Features and Benefits:
  • FIBER2ANTENNA – The edgeROU joins the ALLIANCE 5G DAS platform as a fiber to the edge active DAS remote.
  • NEW! The latest model of edgeROU supports the fully-occupied 280 MHz of the C-Band with 2×2 MIMO!
  • The edgeROU is the smallest, most attractive, highest power, and lowest cost active DAS remote available!
  • The edgeROU is easy to install, like Wi-Fi, using the same labor skills available from the low-voltage installers already working in your building.
  • The edgeROU is available with integrated antennas or external antenna ports.
  • The edgeROU is aesthetically pleasing, and when installed on the ceiling, it has a low profile with only 1.5” exposed.
  • Each edgeROU provides the entire bandwidth of up to four frequency bands with up to 24 dBm per band before the antennas.
  • Main and addon edgeROU configurations support up to eight bands over a single fiber strand.
  • The edgeROU is available in various models with band configurations to support any venue’s coverage and capacity goals.
  • The edgeROU uses the same headend equipment (iBIU) as all other ALLIANCE DAS remotes.
  • The edgeHUB (located in IDF closets) provides a fiber MUX capability to conserve fiber between the headend and edgeROUs.
  • Each edgeHUB provides power for sixteen edgeROUs.

Features and Benefits:

  • 2W of power per frequency band
  • 4 to 7 frequency bands in one remote
  • Add-on Remote (AOR) provides up to 2 additional frequency bands for future-readiness
  • Up to 9 frequency bands on one fiber strand
  • All ALLIANCE remotes use the iBIU headend providing maximum design flexibility

Features and Benefits:
  • 5W of power per frequency band
  • 1 to 7 frequency bands in one remote
  • Add-on Remote (AOR) provides up to 2 additional frequency bands for future-readiness
  • Up to 9 frequency bands on one fiber strand
  • Available with one or two antenna ports
  • All ALLIANCE remotes use the iBIU headend providing maximum design flexibility

Features and Benefits:
  • 20W and 40W options for power per frequency band
  • 1 to 4 frequency bands per cabinet
  • The main cabinet, HROU, is fiber-fed from the headend
  • Expansion cabinet, HARU, has coaxial connections to HROU
  • Up to 8 frequency bands on one fiber strand
  • Available with one, two, or four antenna ports
  • All ALLIANCE remotes use the iBIU headend providing maximum design flexibility

ALLIANCE MID-BAND HROU

ALLIANCE MID-BAND HROU
Documentation Resources
Features and Benefits:
  • Supports C-Band (3.7 to 3.98 GHz) and DOD / Auction 110 (3.45 to 3.55 GHz)
  • Up to 4 amplifiers supporting SISO or MIMO over a single fiber
  • 32W output power for C-Band and 20W output for Auction 110
  • Fully occupied bandwidth in every band
  • Available with one or two antenna ports
  • Rugged construction:  UL Type 4X certified
  • All ALLIANCE remotes use the iBIU headend providing maximum design flexibility

Features and Benefits:
  • 5W (600 and 700 MHz) and 20W (850, 1900, 2100, 2300, 2500 MHz) power per frequency band
  • 1 to 7 frequency bands per cabinet on one fiber strand
  • Supports all commercial bands from 600 to 2700 MHz
  • Multi-band combiner provides one antenna port
  • External fan cooled
  • Rugged construction:  UL Type 4X certified
  • All ALLIANCE remotes use the iBIU headend providing maximum design flexibility

Features and Benefits:
  • Integrates all headend features in a compact 4RU chassis
  • Fully modular to protect your investment
  • Up to sixteen RF service connections per chassis
  • Secondary chassis option available for additional services
  • Uplink and downlink Automatic Level Control (ALC) for each service
  • AC and DC power supply options
  • RF conditioning Points of Interface (POI)
  • POI’s available in high-power, low-power, and hybrid versions
  • Duplex and simplex connections supported
  • Two optical modules support up to 8 remotes
  • Optical expansion to additional remotes via iODU & iOEU

ALLIANCE DMS

DAS Management System

ALLIANCE DMS
Documentation Resources
Features and Benefits:
  • ioXt Certified
  • Real-time alarm monitoring and control
  • Centralized management of the DAS network
  • Web-based management
  • Configurable SNMP traps
  • Supports private MIB files
  • Alarm control hysteresis, alert level, troubleshooting, masking
  • E-mail notification
  • Historical device trend data
  • Automatic and manual backup and restore
  • Programmable dry contacts
